YUFFENBrand: YUFFEN Materials: PET, PP, PC, PI, etc. Thickness: 25um-500um Color: Clear, White, Blac
| PROPERTIES | TEST METHOD (ASTM) | UNIT | TYPICAL VALUE | |
| THICKNESS | D-2673 | Micron (Mil) | 20 30 40 0.8 1.2 1.6 | |
| FILM DENSITY GRAMMAGE YIELD CORONA LEVEL/ WETTING TENSILE COEFF OF FRICTION (Corona/ Non) HAZE JOINTS NUMBER SECTION FLETNESS | D-792 International International D-2578 D-1894 D-1003 International International | gm/cc gm/m2 m2/kg Dyne/cm - - m2 - | 0.91 0.91 0.91 18.2 27.3 36.4 54.9 36.6 27.5 38 38 38 0.3/0.15 0.3/0.15 0.3/0.15 3.9 4.2 4.5 ≤1 ≤2mm | |
| TENSILE STRENGTH AT BREAK | D-882 | MPa (KPsi) | 48 53 65 33 34 35 7.0 7.9 9.42 4.8 4.9 5.07 | |
| ELONGATION AT BREAK | MD* TD* MD* TD* | D-882 | % | 529 540 572 700 711 722 |
| HEAT SEAL TEMPERATURE | MD* TM* | 1s, 300MPa, 60℃for under layer | ℃ | 130 135 140 |
| HEAT SEALING STRENGTH | D-882 | N/15mm | ≥7.2 ≥7.9 ≥8.6 | |
| FINISH | No Folding, Air bubble fracture, Perforation, scratches, impurities, oi | |||
Feature
1. Paste, fixed, conductive shielding, conductive shielding, insulation.
2. Fire, flame, shock buffer, dustproof, anti-skid.
3. Backlit, high temperature, corrosion, sealing, protection
4. Spraying shelter, insulation, noise, filtering.
5. Customers may require professional precision die-processed into a variety of shapes.
1. Insulating sheet has an insulating sheet PET, PP insulation sheet, PC insulating sheet, PVC insulation sheets, etc.,
2. in black, white, transparent and other colors,
3. thickness is generally between 0.125mm ~ 2mm! PC plate (polycarbonate),
4.Excellent performance for engineering plastics, has outstanding physical, mechanical, electrical and thermal properties, so it has the "king of plastic" reputation.
Application
insulation OA, AV, general motors, motors, refrigerators, air-condition, computers, mobile phones, PDA and other products.
